Weight 6 kg
Dimensions 35 × 20 × 15 in
Warranty

1 Year

Material

Alloy

Power

Battery

Model

GS-200G

Range

-20℃ to 55℃

Pixel

2 * 20 million

Brand Name

Geosun

Accuracy

Horizontal 0.02m, Elevation 0.03m

Power Supply

Range 12-20V

System Power Consumption

<25W

The Latest Lidar 3D Laser Scanner GS-200G Cheap and High-Precision for Geological Surveying Equipment

In Stock

₦4,560,530.74

In Stock

Did you like this product? Add to favorites now and follow the product.

Add to wishlist
Have a Question? Ask a Specialist

Start Live Chat

Low Prices

Price match guarantee

Guaranteed Fitment.

Always the correct part

In-House Experts.

We know our products

Easy Returns.

Quick & Hassle Free

Categories: ,

Description

System Indicators​
Point Cloud Accuracy
Relative accuracy ≤1cm; Absolute accuracy ≤5cm
Power Supply Range
12-20V
Dimensions
16.5 * 12.0 * 32.4cm
Device Weight
1.0kg
Operating Temperature
-20℃ to 55℃
System Power Consumption
<25W
Storage Space
128G SD card
Mounting Platform
Handheld/Backpack/Airborne/Vehicle-mounted
​POS Performance Indicators​
Model
gSpin 210
Roll Angle Accuracy
0.015°
Data Update Frequency
200 Hz
Heading Angle Accuracy
0.040°
Positioning Accuracy
Horizontal 0.02m, Elevation 0.03m
Pitch Angle Accuracy
0.015°
GNSS Signal Types
GPS L1/L2; GLO L1/L2; GAL E1/E5b; BDS B1/B3/B2a (Supports single BeiDou mode)
​Laser Performance Indicators​
Measuring Range
40m@10%, 70m@80%
Horizontal Field of View
360°
Point Frequency
200,000 points/sec (single return)
Ranging Accuracy
≤2cm@10m, ≤3cm@0.2m
Vertical Field of View
-7° to 52°
Scanning Method
Non-repetitive scanning
​Camera Indicators​
Pixel
2 * 20 million
Field of View
Horizontal 200°, Vertical 200°
Shooting Mode
Time-lapse shooting
​Mapping​
SLAM; RTK-SLAM; PPK-SLAM
